1 channel 2π - Bolometer 4 channels replacement bolometer

absorber Gold thickness 1..15µm heat flow layer Gold 0,02..0,08µm Resistors gold, platinum carrier foil Capton®, glimmer, ceramics 8..15µm Bridge voltage 20VAC resistance R > 3..5kΩ size 25mm × 50..70mm

16 channels bolometer on a chip (BOC)

absorber Gold thickness 1..15µm heat flow layer Gold 0,02..0,08µm Resistors gold, platinum carrier foil Capton®, glimmer, ceramics 8..15µm Bridge voltage 20VAC resistance R > 1kΩ

32 channels bolometer on a chip (BOC)

absorber Gold thickness 1..15µm heat flow layer Gold 0,02..0,08µm Resistors gold, platinum carrier foil Capton®, glimmer, ceramics 8..15µm Bridge voltage 20VAC resistance R > 1kΩ

16 channel feed back bolometer on a chip (BOC)

absorber Gold thickness 1..15µm heat flow layer Gold 0,02..0,08µm Resistors gold, platinum carrier foil Capton®, glimmer, ceramics 8..15µm Bridge voltage 20VAC resistance R > 1kΩ

32 channels feed back bolometer on a chip (BOC)

absorber Gold thickness 1..15µm heat flow layer Gold 0,02..0,08µm Resistors gold, platinum carrier foil Capton®, glimmer, ceramics 8..15µm Bridge voltage 20VAC resistance R > 1kΩ

64 channels feed back camera with 2 BOC's

absorber Gold thickness 1..15µm heat flow layer Gold 0,02..0,08µm Resistors gold, platinum carrier foil Capton®, glimmer, ceramics 8..15µm Bridge voltage 20VAC resistance R > 1kΩ

160 channels feed back camera with 5 BOC's

absorber Gold thickness 1..15µm heat flow layer Gold 0,02..0,08µm Resistors gold, platinum carrier foil Capton®, glimmer, ceramics 8..15µm Bridge voltage 20VAC resistance R > 1kΩ
